OMGA FJL 183

$103,441

plus 20% VAT, $124,130 gross
OMGA FJL 183
OMGA FJL 183
OMGA FJL 183
OMGA FJL 183
OMGA FJL 183
OMGA FJL 183
OMGA FJL 183
OMGA FJL 183
Location 410223 Bucharest, Romania
Condition Used
Advertiser status Commercial
Year of manufacture 2008
Advert number 2817110
Internal reference number Finger jointing line
Machine status Active

Further Descriptions

Finger jointing line
id. 987
Max. piece thickness: 3 1/8"
Max. piece width: 6"
Max. piece length: 36"
Min. piece length: 6"
Max. pressing length: 14' - 20' - 30'
Cope spindle motor power: 2 X 20 HP - (30 HP Opt.)
Hogging saw motor power: 2 X 10 HP - (15 HP Opt.)
Scoring saw motor power: 2 X 2 HP
Hydraulic press 26,000 lbs.
Max. production rate 4.5 batch/min
Production rate FPM (input pieces of 3 1/2"x1 1/2"x14"): 115 FP
Workpiece width max 150 mm
Workpiece thickness max 80 mm
Infeed length max 1000 mm
Package width 750 mm
Pressing length 6100 mm
Milling machine Double-sided milling machine
Conveyor/ separator: fully automatic
End press, Horizontal joint , Vertical jointNumber of milling units: 2
Infeed length min 150 mm
Capacity of router cycles/min: 3
Loading via belt conveyor with boxes
Scoring aggregate: 1
Milling feed
Mobile table, fix aggregates
Gluing with profile nozzles

Ex Works Bucharest

We speak English. Wir sprechen Deutsch. (+40 740-221.698 )
Hablamos Espanol. Beszelunk magyarul. (+40 743-177.040 )

Irrtum, Anderungen und Zwischenverkauf vorbehalten /
Subject to errors, changes and prior sale /
Ne rezervam dreptul la greseli, modificari si vanzare prealabila.
