Satvia VB400

Price on application

Satvia VB400
Satvia VB400
Satvia VB400
Satvia VB400
Satvia VB400
Satvia VB400
Location 89343 Jettingen-Scheppach, Germany
Financing available
Condition New
Advertiser status Commercial
Year of manufacture 2005
Operating weight 33,000 kg
Advert number 5115786
Machine status Active

Further Descriptions

full hydraulic operated drilling rig, type VB 400, constructed and designed for rotary drilling with mud circulation, with reverse mud circulation by airlifting and also DTH-Hammer drilling and dry drilling.

Hook load gross capacity 250 kN; Mast length 11.5 m; Max. torque 16,000 Nm
Clamping device: Max. free passage- when closed 250 mm; Max. clamping capacity 700 kN; Clamping jaw inserts 1 set for 4½" DP
Hoising Equipment: Drive hydraulic; Max. line pull 50 kN; Rope diameter 16 mm; Rope capacity / Length 120 m / 120 m ; Brake device hydraulic release
